ABS-ESD7™
Material Data Sheet
ABS-ESD7™ (acrylonitrile butadiene styrene-electrostatic dissipative) is an ABS thermoplastic with static dissipative properties for applications where a static charge can damage products impair their performance or cause an explosion.
ABS-ESD7 prevents a buildup of static electricity, so it will not produce a static shock or cause other materials like powders, dust and fine particles to stick to it. Ideal for electronic products with circuit boards and for the transportation and industrial equipment industries.
Most widely used to create jigs and fixtures for the assembly of electronic components, but is also useful for building functional prototypes of fuel storage and delivery products, as well as cases, enclosures and packaging.
Color options:
Black
Quick Facts:
- Static dissipative properties
- Ideal for electronics
- Great for uses with fuel and packaging
| Mechanical Properties | Test Method | English | Metric |
|---|---|---|---|
| Tensile Strength (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 5,200 psi | 36 MPa |
| Tensile Modulus (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 350,000 psi | 2,400 MPa |
| Tensile Elongation (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 3% | 3% |
| Flexural Strength (Method 1, 0.05”/min) | ASTM D790 | 8,800 psi | 61 MPa |
| Flexural Modulus (Method 1, 0.05”/min) | ASTM D790 | 350,000 psi | 2400 MPa |
| IZOD Impact, notched (Method A, 23°C) | ASTM D256 | .5 ft-lb/in | 28 J/m |
| IZOD Impact, un-notched (Method A, 23°C) | ASTM D256 | 1.1 ft-lb/in | 55 J/m |
| Thermal Properties | Test Method | English | Metric |
|---|---|---|---|
| Heat Deflection (HDT) @ 66 psi, 0.125” unannealed | ASTM D648 | 204° F | 96° C |
| Heat Deflection (HDT) @ 264 psi, 0.125” unannealed | ASTM D648 | 180° F | 82° C |
| Vicat Softening Temperature (Rate B/50) | ASTM D1525 | 210° F | 99° C |
| Glass Transition (Tg) | DSC (SSYS) | 226° F | 108° C |
| Coefficient of Thermal Expansion (flow) | ASTM E831 | 4.9E-05in/in/° F | 8.82-05mm/mm/° C |
| Coefficient of Thermal Expansion (xflow) | ASTM E831 | 4.7E-05in/in/° F | 8.46-05mm/mm/° C |
| Melting Point | ———— | Not Applicable | Not Applicable |
| Electrical Properties | Test Method | Value Range |
|---|---|---|
| Volume Resistivity | ASTM D257 | 3.0×10-9 – 4.0×10-10 ohm-cm |
| Surface Resistance | ASTM D257 | 10-6 – 10-9 ohms |
| Other | Test Method | Value |
|---|---|---|
| Specifid Gravity | ASTM D792 | 1.04 |
| Flame Classification | UL94 | HB (0.06”, 1.5 mm) |
| Rockwell Hardness | ASTM D785 | 109.5 |
