PC-ISO
Material Data Sheet
PC-ISO
PC-ISO (polycarbonate-ISO), a strong industrial thermoplastic, which in its raw state, is biocompatible and can be gamma or EtO sterilized. It is commonly used in food packaging and manufacturing.
Color options:
White, Translucent Natural
Quick Facts:
- Industrial strength
- Biocompatible
- Common in food and drug packaging
| Mechanical Properties | Test Method | English | Metric |
|---|---|---|---|
| Tensile Strength (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 8,300 psi | 37 MPa |
| Tensile Modulus (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 289,800 psi | 2,000 MPa |
| Tensile Elongation (Type 1, 0.125”, 0.2”/min) | ASTM D638 | 4% | 4% |
| Flexural Strength (Method 1, 0.05”/min) | ASTM D790 | 13,100 psi | 90 MPa |
| Flexural Modulus (Method 1, 0.05”/min) | ASTM D790 | 310,400 psi | 2,100 MPa |
| IZOD Impact, notched (Method A, 23°C) | ASTM D256 | 1.6 ft-lb/in | 86 J/m |
| IZOD Impact, un-notched (Method A, 23°C) | ASTM D256 | 1 ft-lb/in | 53 J/m |
| Thermal Properties | Test Method | English | Metric |
|---|---|---|---|
| Heat Deflection (HDT) @ 66 psi | ASTM D648 | 271°F | 133°C |
| Heat Deflection (HDT) @ 264 psi | ASTM D648 | 260°F | 127°C |
| Vicat Softening Temperature | ASTM D1525 | 234°F | 112°C |
| Glass Transition Temperature (Tg) | DMA (SSYS) | 322°F | 161°C |
| Vicat Softening | ISO 306 | 282°F | 139°C |
| Melt Point | – – – – – – – – – | Not Applicable | Not Applicable |
| Electrical Properties | Test Method | Value Range |
|---|---|---|
| Volume Resistivity | ASTM D257 | 1.5x10e14 – 8.0x10e13 ohm-cm |
| Dielectric Constant | ASTM D150-98 | 3.0 – 2.8 |
| Dissipation Factor | ASTM D150-98 | .0009 – .0005 |
| Dielectric Strength | ASTM D149-09, Method A | 370 – 70 V/mil |
| Other | Test Method | Value |
|---|---|---|
| Specific Gravity | ASTM D792 | 1.2 |
| Flame Classification | UL94 | HB |
Download pfd for technical specifications.
